| ENGINE | |
| Type | 123.9cc air-cooled single-cylinder four-stroke |
| Valvetrain | SOHC; 2 valves |
| Bore x Stroke | 50.0mm x 63.1mm |
| Compression Ratio | 10.0:1 |
| Induction | Programmed electronic fuel injection (PGM-FI) w/ 24mm bore, automatic enrichment |
| Ignition | Full transistorized |
| Starter | Push-button electric |
| Transmission | Manual 4-speed |
| Clutch | Semiautomatic; multiplate wet |
| Final Drive | Chain; 15T/34T |
| SUSPENSION | |
| Front | 31mm telescopic inverted fork; 4.3-inch travel |
| Rear | Twin shocks; 4.7-inch travel |
| BRAKES | |
| Front | Single hydraulic two-piston caliper w/ 220mm disc |
| Rear | Single hydraulic one-piston caliper w/ 190mm disc |
| TIRES | |
| Front | 120/70-12 |
| Rear | 130/70-12 |
| MEASUREMENTS | |
| Rake | 25.0º |
| Trail | 3.3 inches (84mm) |
| Length | 69.3 inches |
| Width | 30.0 inches |
| Height | 40.1 inches |
| Ground Clearance | 7.0 inches |
| Seat Height | 30.6 inches |
| Wheelbase | 47.2 inches |
| Fuel Capacity | 1.0 gallons |
| Curb Weight* | 236 pounds |
| OTHER | |
| Color | Pearl Black |
| Warranty | 1 year |
*Includes all standard equipment, required fluids and full tank of fuel—ready to ride
Meets current EPA standards
Models sold in California meet current CARB standards and may differ slightly due to emissions equipment
